ASTRO Bifacial Series Solar Panels ASTRO 5 Twins CHSM72M(DG)/F-BH 540-560W Monocrystalline P-Type Double Glass PV Module For On-Grid Solar System
Astronergy PV modules can be widely used on rooftop and ground solar farms. Astronergy strengthens technological innovation and R&D investment, and continues to launch ASTRO series of high-efficient modules, covering ASTRO monocrystalline bifacial series and ASTRO monocrystalline mono-facial series, using a number of advanced photovoltaic technologies such as large-format silicon wafers, half-cutting, MBB, non-destructive cutting to increase module power and efficiency, and have obtained certifications in many mainstream markets including China, Europe, Australia, Japan, South Korea, Israel, Brazil, the United States, etc., with metrics reaching the international first-class level. With a reliable and technology-leading brand, Astronergy has won the honor of PVEL/DNV GL “Top Performer” top module manufacturer for seven times, and has been listed as the world’s Tier 1 supplier of photovoltaic modules by Bloomberg, an international authoritative financial company, for many times.
Solar panels are engineered for maximum efficiency, capturing sunlight and converting it into electricity with remarkable precision. Solar panels incorporate the latest advancements, ensuring you benefit from the most efficient and reliable solar solutions available on the market.
From extreme weather conditions to daily wear and tear, solar panels are designed to provide long-lasting, reliable performance, ensuring a sound investment in your energy future.
With solar panels, you’re actively contributing to the reduction of greenhouse gas emissions and promoting a cleaner, healthier planet for generations to come.
Type | Monocrystalline | ||||
Model No. | 540 | 545 | 550 | 555 | 560 |
Warranty | |||||
Product Warranty | 15 Years | ||||
Power Warranty | 30 Years of 84.95% Output Power | ||||
Electrical Data at STC | |||||
Maximum Power (Pmax) | 540 Wp | 545 Wp | 550 Wp | 555 Wp | 560 Wp |
Voltage at Maximum Power (Vmpp) | 41.93 V | 42.1 V | 42.27 V | 42.44 V | 42.61 V |
Current at Maximum Power (Impp) | 12.88 A | 12.95 A | 13.01 A | 13.08 A | 13.14 A |
Open Circuit Voltage (Voc) | 49.9 V | 50.1 V | 50.3 V | 50.5 V | 50.7 V |
Short Circuit Current (Isc) | 13.66 A | 13.75 A | 13.84 A | 13.89 A | 13.98 A |
Panel Efficiency | 20.90% | 21.10% | 21.30% | 21.50% | 21.70% |
Standard Test Conditions (STC): air mass AM 1.5, irradiance 1000W/m2, cell temperature 25°C | |||||
Electrical Data at NOCT | |||||
Maximum Power (Pmax) | 403.5 Wp | 407.3 Wp | 411 Wp | 414.8 Wp | 418.5 Wp |
Voltage at Maximum Power (Vmpp) | 39.08 V | 39.24 V | 39.39 V | 39.55 V | 39.71 V |
Current at Maximum Power (Impp) | 10.33 A | 10.38 A | 10.43 A | 10.49 A | 10.54 A |
Open Circuit Voltage (Voc) | 47.16 V | 47.34 V | 47.53 V | 47.72 V | 47.91 V |
Short Circuit Current (Isc) | 11.08 A | 11.16 A | 11.23 A | 11.3 A | 11.37 A |
Temperature | 41±2 °C | ||||
Nominal Operating Cell Temperature (NOCT): 800W/m2, AM 1.5, windspeed 1m/s,ambient temperature 20°C | |||||
Thermal Ratings | |||||
Temperature Coefficient of Pmax | -0.34 %/°C | ||||
Temperature Coefficient of Voc | -0.25 %/°C | ||||
Temperature Coefficient of Isc | 0.04 %/°C | ||||
Maximum Ratings | |||||
Maximum System Voltage | 1500 V | ||||
Series Fuse Rating | 30 A | ||||
Material Data | |||||
Panel Dimension (H/W/D) | 2278x1134x35 mm | ||||
Weight | 32.1 kg | ||||
Cell Number | 144 | ||||
Glass Thickness | 2 mm | ||||
Frame Type | Anodized Aluminium | ||||
Junction Box Diodes | 3 | ||||
Junction Box Protection Class | IP 68 | ||||
Connector Type | MC4 | ||||
Cable Crossection | 4 mm2 |
