Solis Hybrid Solar Inverter RHI-3P10K-HVES-5G 10kW 400V Three Phase Solution For Residential Solar Power System Compatible 160-600V Lithium Battery
$2,730.00
RHI-3P(3-10)K-HVES-5G series inverter is energy storage hybrid solar inverter combines the advantages of grid tied inverters and off-grid inverters. It can not only feedback surplus electricity to public grid to get margin, but can also be used in conjunction with solar batteries to maximize the power generated by solar panels. utilization.
Solis Hybrid Solar Inverter RHI-3P10K-HVES-5G 10kW 400V Three Phase Solution For Residential Solar Power System Compatible 160-600V Lithium Battery
The Solis RHI-3P hybrid solar inverter is the perfect choice for storage solutions in three-phase photovoltaic systems. Higher returns: select the electricity consumption mode in real time based on the market price, it also boasts high independence via the EPS function to give you energy even in the event of a blackout.
It has greater efficiency: we use components from leading international brands to guarantee durability and efficiency and has very fast switching: less than 40ms.
RHI-3P(3-10)K-HVES-5G Hybrid Solar Inverter
UPS function, Less than 40ms reaction, does not affect the power supply of important loads; 24 hours solar energy use; save money up to zero cost;
Optional 24-hour load consumption monitoring solutionfanless design, long lifespan; Easy monitor setup via remote APP settings;
Regulate peak and valley electricity consumption, low-cost charging at night, and high-priced electricity sales at daytime;
Easy O & M, remotely control and upgrade any selected inverter, making digital power plant maintenance at your fingertips.
Solis Three Phase High Voltage Energy Storage Hybrid Solar Inverter
- Max. efficiency 98.4%
- Intelligent EMS function
- Support three-phase imbalance on backup output port
- 2 MPPT and 4 DC input; Max 26A DC input current
- Time of use shifting and peak shaving capabilities to grid
- Solis supply optional arc fault circuit interrupter (AFCI) function
- Power supply can be switched automatically and switching time within 40ms
- Ensures AC backup for up to 10kW of continuous power and 16kVA of peak power
- 24-hour fully intelligent energy management, Real-time grasp of PV plant status
- Remotely control & upgrade function, making digital power plant maintenance at your fingertips
- 3 operating modes (self-consumption; time-of-use; off-grid back-up) & programmable energy management
| Models | 3K | 4K | 5K | 6K | 8K | 10K | |||
| Input DC (PV side) | |||||||||
| Recommended max. PV power | 4.8 kW | 6.4 kW | 8 kW | 9.6 kW | 12.8 kW | 16 kW | |||
| Max. input voltage | 1000 V | ||||||||
| Rated voltage | 600 V | ||||||||
| Start-up voltage | 160 V | ||||||||
| MPPT voltage range | 200-850 V | ||||||||
| Max. input current | 13 A / 13 A | 26 A / 13 A | 26 A / 26 A | ||||||
| Max. short circuit current | 16.5 A / 16.5 A | 32.5 A / 16.5 A | 32.5 A / 32.5 A | ||||||
| MPPT number/Max. input strings number | 2/2 | 2/3 | 2/4 | ||||||
| Battery | |||||||||
| Battery type | Li-ion | ||||||||
| Battery voltage range | 160-600 V | ||||||||
| Max. charge / discharge power | 3 kW | 4 kW | 5 kW | 6 kW | 8 kW | 10 kW | |||
| Max. charge / discharge current | 25 A | ||||||||
| Communication | CAN | ||||||||
| Input AC (Grid side) | |||||||||
| Input voltage range | 320-480 V | ||||||||
| Max. apparent input power | 3 kVA | 4 kVA | 5 kVA | 6 kVA | 8 kVA | 10 kVA | |||
| Max. input current | 25 A | ||||||||
| Frequency range | 45-55 Hz / 55-65 Hz | ||||||||
| Output AC (Grid side) | |||||||||
| Rated output power | 3 kW | 4 kW | 5 kW | 6 kW | 8 kW | 10 kW | |||
| Max. apparent output power | 3.3 kVA | 4.4 kVA | 5.5 kVA | 6.6 kVA | 8.8 kVA | 10 kVA | |||
| Operation phase | 3/N/PE | ||||||||
| Rated grid voltage | 380 V / 400 V | ||||||||
| Rated grid frequency | 50 Hz / 60 Hz | ||||||||
| Rated grid output current | 4.6 A / 4.4 A | 6.1 A / 5.8 A | 7.6 A / 7.3 A | 9.2 A / 8.7 A | 12.2 A / 11.6 A | 15.2 A / 14.5 A | |||
| Max. output current | 5.1 A | 6.8 A | 8.4 A | 10 A | 13.4 A | 16.7 A | |||
| Power factor | >0.99 (0.8 leading – 0.8 lagging) | ||||||||
| THDi | <2% | ||||||||
| Output AC (Back-up) | |||||||||
| Rated output power | 3 kW | 4 kW | 5 kW | 6 kW | 8 kW | 10 kW | |||
| Peak apparent output power | 10 kVA, 60 sec | 10 kVA, 60 sec | 10 kVA, 60 sec | 12 kVA, 60 sec | 16 kVA, 60 sec | 16 kVA, 60 sec | |||
| Back-up switch time | < 40 ms | ||||||||
| Rated output voltage | 3/N/PE, 380 V / 400 V | ||||||||
| Rated frequency | 50 Hz / 60 Hz | ||||||||
| Rated output current | 4.6 A / 4.4 A | 6.1 A / 5.8 A | 7.6 A / 7.3 A | 9.2 A / 8.7 A | 12.2 A / 11.6 A | 15.2 A / 14.5 A | |||
| THDv (@linear load) | <2% | ||||||||
| Efficiency | |||||||||
| Max. efficiency | 98.4% | ||||||||
| EU efficiency | 97.7% | ||||||||
| MPPT efficiency | 99.9% | ||||||||
| Battery charge/discharge efficiency | 97.5% | ||||||||
| Protection | |||||||||
| Anti-islanding protection | Yes | ||||||||
| Output over current protection | Yes | ||||||||
| Short circuit protection | Yes | ||||||||
| Integrated AFCI | Yes | ||||||||
| Integrated DC switch | Optional | ||||||||
| DC reverse-polarity protection | Yes | ||||||||
| PV over voltage protection | Yes | ||||||||
| Battery reverse protection | Yes | ||||||||
| General Data | |||||||||
| Dimensions (W*H*D) | 535*455*185 mm | ||||||||
| Weight | 25.1 kg | ||||||||
| Topology | Transformerless | ||||||||
| Standby consumption | <15 W | ||||||||
| Operating ambient temperature range | -25 ~ +60°C | ||||||||
| Relative humidity | 0-100% | ||||||||
| Ingress protection | IP65 | ||||||||
| Cooling concept | Natural convection | ||||||||
| Max. operation altitude | 4000 m | ||||||||
| Grid connection standard | G98 or G99,VDE-AR-N 4105 / VDEV 0124, EN 50549-1,VDE 0126 / UTE C 15/VFR:2019, RD 1699/RD 244 / UNE 206006 / UNE 206007-1, CEI 0-21, C10/11, NRS 097-2-1, EIFS 2018.2, IEC 62116, IEC 61727, IEC 60068, IEC 61683, EN 50530, MEA, PEA | ||||||||
| Safety/EMC standard | IEC/EN 62109-1/-2, IEC/EN 61000-6-1/-3 | ||||||||
| Features | |||||||||
| DC connection | MC4 connector | ||||||||
| AC connection | Quick connection plug | ||||||||
| Display | LCD | ||||||||
| Communication | RS485, Optional: Wi-Fi, GPRS | ||||||||
| Weight | 27 kg |
|---|---|
| Dimensions | 70 × 60 × 30 cm |
| Brand | |
| Battery Type |
Lithium-ion |
| Max. Charging Current(A) |
25 |
| Battery Voltage Range(V) |
160-600 |
| Max PV Input Power(W) |
16K |
| Max PV Input Voltage(V) |
1000 |
| MPPT Voltage Range(V) |
200-850 |
| No. Of MPPT |
2/2+1 |
| Number of battery input |
1 |
| Rated AC Input/Output Active Power(W) |
10000 |
| Rated Input/Output Grid Frequency/Range |
50Hz/45Hz-55Hz ,60Hz/55Hz-65Hz |
| Rated Input/Output Voltage/Range(V) |
230/400V |
Solis is a leading global manufacturer of solar inverters and energy storage solutions. They offer a wide range of inverter products for residential, commercial, and utility-scale solar applications.
Some key things to know about Solis inverters:
Product Overview:
Solis offers both string inverters and microinverters/power optimizers.
Their inverter models range from small single-phase units for residential use to large 3-phase central inverters for utility-scale solar farms.
Solis has a strong focus on reliability, efficiency, and advanced grid support features.
Key Features:
High conversion efficiency, often exceeding 98% peak efficiency
Dual MPPT inputs for flexible system design
Integrated DC and AC surge protection
Advanced grid support functions like volt/var control, voltage ride-through
Remote monitoring and control capabilities
Modular and scalable design options
Applications:
Residential rooftop solar
Commercial and industrial solar installations
Ground-mounted utility-scale solar power plants
Hybrid solar + energy storage systems
Warranty:
Solis offers standard 5-year warranties on their inverters
Extended warranty options up to 20 or 25 years are available
MAECENAS IACULIS
Vestibulum curae torquent diam diam commodo parturient penatibus nunc dui adipiscing convallis bulum parturient suspendisse parturient a.Parturient in parturient scelerisque nibh lectus quam a natoque adipiscing a vestibulum hendrerit et pharetra fames nunc natoque dui.
ADIPISCING CONVALLIS BULUM
- Vestibulum penatibus nunc dui adipiscing convallis bulum parturient suspendisse.
- Abitur parturient praesent lectus quam a natoque adipiscing a vestibulum hendre.
- Diam parturient dictumst parturient scelerisque nibh lectus.
Scelerisque adipiscing bibendum sem vestibulum et in a a a purus lectus faucibus lobortis tincidunt purus lectus nisl class eros.Condimentum a et ullamcorper dictumst mus et tristique elementum nam inceptos hac parturient scelerisque vestibulum amet elit ut volutpat.
SOLIS-DATASHEET-RHI-3P3-10K-HVES-5G-GLOBAL
SOLIS-MANUAL-RHI-3P3-10K-HVES-5G-EUR-V1,720231017
SOLIS-LEAFLET-BATTERY-MATCHING-RHI-3P3-10K-HVES-5G-V2,3-202406
SOLLIS-CERTIFICATE-IEC-61000-6-1-3-EN-61000-6-1-3-EN-55011-CISPR-RHI-3P3-10K-HVES-5G-CEEMC-V01
SOLLIS-CERTIFICATE-EN-300328-EN-301489-1-17-EN-55011-EN-61000-6-1-3-EN-62109-1-2-EN-62311-RHI-3P3-10K-HVES-5G-RED-V01
SOLIS-CERTIFICATE-IEC62109-12-EN62019-12-RHI-3P5-10K-HVES-5G-V01TUV-MARK-CE
SOLIS-CERTIFICATE-IEC61683-IEC60068-RHI-3P5-10K-HVES-5G-EFFICIENCY-V01
SOLIS-CERTIFICATE-EN50549-1-RHI-3P3-10K-HVES-5G-EUROPE-V01-GL
SOLIS-CERTIFICATE-CE-RHI-3P3-10K-HVES-5G
SOLIS-CERTIFICATE-C10-11-RHI-3P5-10K-HVES-5G-BELGIUM-V01
SOLLIS-CERTIFICATE-VDE4105&VDE0124-RHI-3P5-10K-HVES-5G-GER-V01
