Growatt Off-Grid Storage Hybrid Solar Inverter SPF 5000 TL LVM 48VDC Solar Input Compatible Lithium/Lead-acid Battery For Residential Solar Energy System
$710.00
SKU:
SPF5000TL-HVM-48
Categories: Off-Grid Inverter, Inverter & Controller
Tags: Growatt Inverter, Hybrid Solar Inverter, Off-Grid Solar Inverter
Growatt Off-Grid Storage Hybrid Solar Inverter SPF 5000 TL LVM 48VDC solar input compatible Lithium/Lead-acid Battery For Residential Solar Energy System
Growatt off grid solar hybrid inverter, is a great choice for people looking for a reliable and efficient power solution when living off the grid. With its advanced features and flexible design, this inverter offers many benefits for off-grid applications.
One major advantage of the Growatt SPF inverter is its ability to provide a steady power supply in remote areas or during power outages. It lets you use solar energy and store it in batteries for later use. This ensures a continuous power source, giving you energy independence and reliability in your off-grid lifestyle.
The Growatt off-grid inverter comes in two power options: the 3500W model and the 5000W model. The 3500W model is suitable for small-scale uses like cabins, RVs, or small off-grid homes. It can power essential appliances and electronics, making your off-grid living convenient and comfortable.
The 5000W model is ideal for larger off-grid systems, such as medium-sized homes or remote installations. With its higher power capacity, it can handle a wider range of appliances and equipment, providing a comprehensive off-grid power solution that meets your energy needs.
Both models of the Growatt off-grid inverter have impressive features. They use advanced MPPT (Maximum Power Point Tracking) technology to optimize the conversion of solar energy into usable electricity. This ensures maximum efficiency in your off-grid system and improves overall performance.
Additionally, these inverters have comprehensive protection mechanisms, including safeguards against overvoltage, short circuits, and high temperatures. These safety features ensure the durability and reliability of your off-grid power system, protecting your investment and giving you peace of mind.
The user-friendly design is another standout feature. It has a simple interface and intuitive controls, making installation and operation easy. Even if you’re not a technical expert, you can set up and manage your off-grid power system effectively.
Furthermore, the Growatt off-grid inverter is built to withstand tough environmental conditions. Its strong construction and durability allow it to handle extreme temperatures and challenging weather, making it suitable for various off-grid applications, including remote areas with harsh climates.
In conclusion, Growatt off grid inverter, offers many advantages for off-grid power systems. With its uninterrupted power supply, flexible power options, advanced features, user-friendly design, and durability, it provides a reliable and efficient solution for your off-grid energy needs. Whether you choose the 3500W or 5000W model, the Growatt off-grid inverter ensures optimal performance and long-term energy independence for your off-grid lifestyle.
Key Features:
High Yields
– 2 times peak power ability
– Output power factor up to 1.0
– The max. efficiency up to 93%
Scalable & Flexible
– Multi-customized modes for diverse scenarios
– Max. 6 units in parallel for capacity extension
– Support multiple power sources, such as PV, battery, diesel generator and utility
Smart & Reliable
– Support WiFi and GPRS remote monitoring
– PVkeeper platform for local commissioning
– Battery reverse connection protection
Datasheet | SPF 2000TL HVM-24 | SPF 3000TL HVM-24 | SPF 2000TL HVM-48 | SPF 3000TL HVM-48 | SPF 5000TL HVM/HVM-P |
Battery Voltage | 24VDC | 48VDC | |||
Battery Type | Lithium/Lead-acid | ||||
INVERTER OUTPUT | |||||
Rated Power | 2000VA/ 2000W | 3000VA/ 3000W | 2000VA/ 2000W | 3000VA/ 3000W | 5000VA/ |
5000W | |||||
Parallel Capability | No | 6 units maximum | |||
AC Voltage Regulation (Battery Mode) | 230VAC ± 5% @ 50/60Hz | ||||
Surge Power | 4000VA | 6000VA | 4000VA | 6000VA | 10000VA |
Efficiency (Peak) | 93% | ||||
Waveform | Pure sine wave | ||||
Transfer Time | 10ms typical, 20ms Max | ||||
SOLAR CHARGER | |||||
Maximum PV Array Power | 1500W | 1800W | 4500W | ||
MPPT Range @ Operating Voltage | 30VDC ~ 80VDC | 60VDC ~ 115VDC | |||
Maximum PV Array Open Circuit Voltage | 102VDC | 145VDC | |||
Number of Independent MPP Trackers/ Strings Per MPP Tracker | 1/1/1 | ||||
Maximum Solar Charge Current | 50A | 30A | 80A | ||
Maximum Efficiency | 98% | ||||
AC CHARGER | |||||
Charge Current | 30A | 15A | 60A | ||
AC Input Voltage | 230 VAC | ||||
Selectable Voltage Range | 170-280 VAC (For Personal Computers) ; 90-280 VAC (For Home Appliances) | ||||
Frequency Range | 50Hz/60Hz (Auto sensing) | ||||
PHYSICAL | |||||
Protection Degree | IP20 | ||||
Dimension (W/H/D) | 315/400/130mm | 350/455/130mm | |||
Net Weight (kgs) | 8 | 8.5 | 8 | 8.5 | 11.5 |
OPERATING ENVIRONMENT | |||||
Humidity | 5% to 95% Relative Humidity(Non-condensing) | ||||
Altitude | <2000m | ||||
Operating Temperature | 0°C – 55°C | ||||
Storage Temperature | -15°C – 60°C |
Weight | 10 kg |
---|---|
Dimensions | 40 × 50 × 30 cm |
Brand | |
Battery Type |
Lead-acid ,Lithium-ion |
Max. Charging Current(A) |
60 |
Battery Voltage Range(V) |
48 |
Max PV Input Power(W) |
4500 |
Max PV Input Voltage(V) |
145 |
MPPT Voltage Range(V) |
60-115 |
No. Of MPPT |
1/1 |
Number of battery input |
1 |
Rated AC Input/Output Active Power(W) |
5000 |
Rated Input/Output Grid Frequency/Range |
50Hz/45Hz-55Hz ,60Hz/55Hz-65Hz |
Rated Input/Output Voltage/Range(V) |
220V/230V |
