HUAWEI Smart String Solar Inverter SUN2000-50KTL-M3 50KW 380V Three Phase On-Grid FusionSolar PV solutions for Residential/Carport/Commercial
$1,490.00
The HUAWEI Solar Inverter SUN2000-50KTL-M3 Inverter is a reliable and efficient choice for commercial and utility-scale solar applications. Its advanced features, high efficiency, and robust design make it a strong contender for those looking to optimize their solar energy systems.
SKU:
SUN2000-50KTL-M3
Categories: On-Grid Inverter, Inverter & Controller
Tags: Huawei Solar Inverter, On-Grid Solar Inverter, Solar Inverter, Three Phase On-grid Solar Inverter
HUAWEI Smart String Solar Inverter SUN2000-50KTL-M3 50KW 380V Three Phase On-Grid FusionSolar PV solutions for Residential/Carport
The Huawei Solar Inverter SUN2000-50KTL-M3 combines efficiency with ease of use. As an indispensable component of the PV system, the inverter is designed to convert direct current from the solar cells into alternating current. In this form, it can be used or fed into the grid.
- 3-phase inverter with 55,000VA power
- 4 independent MPP trackers
- Efficiency up to 98.5%
- Compatible with module optimizer MERC-1100W-P, MERC-1300W-P
- Communication via 2G, 3G, 4G, Ethernet (with optional dongle), RS485, AC & DC-MBUS
- Free system monitoring with FusionSolar
- RS485 for Smart Power Sensor & SmartLogger
- Integrated AC and DC overvoltage protection TYPE II
- Integrated PID recovery
- intelligent air cooling
- Protection class IP66
Huawei SUN2000-50KTL-M3 – General Data
Betriebstemperaturbereich: -25 ~ +60 °C
Relative Betriebsfeuchtigkeit: 0 % RH~100 % RH
Betriebshöhe: 0 – 4.000 m (Leistungsminderung > 2.000 m)
Kühlung: intelligente Luftkühlung
Anzeige: LED – Anzeige, Bluetooth + APP
Kommunikation: RS485, WLAN/Ethernet via Smart Dongle-WLAN-FE (Optional) 4G / 3G / 2G via Smart Dongle-4G (Optional)
Gewicht (inkl. Befestigungswinkel): 49 kg
Abmessungen (inkl. Befestigungswinkel): 640 x 530 x 270 mm
Schutzart: IP66
Energieverbrauch nachts: < 5,5 W
Huawei SUN2000-50KTL-M3 – Input (DC)
Max. Input voltage1: 1,100 V
Operating voltage range2: 200 V ~ 1,000 V
Starting voltage: 200 V
Rated input voltage: 600 V
Max. Input current per MPPT: 30 A
Max. Short-circuit current: 40 A
Number of MPP trackers: 4
Max. Number of inputs: 8
Huawei SUN2000-50KTL-M3 – protection and function
DC load break switch: Yes
Islanding detection: Yes
DC reverse polarity protection: Yes
String monitoring: Yes
DC overvoltage protection: Yes, compatible with protection type TYPE II according to EN / IEC 61643-11
AC overvoltage protection: Yes, compatible with protection type TYPE II according to EN / IEC 61643-11
Fault current monitoring: Yes
AC overcurrent protection: Yes
DC insulation resistance detection: Yes
Arc detection: Yes
Ripple control receiver inputs: Yes
Integrated PID recovery.3: Yes
Huawei SUN2000-50KTL-M3 – Module Optimizer
DC MBUS compatible optimizer: MERC-1100W-P, MERC-1300W-P
Huawei SUN2000-50KTL-M3 – Standards Compliance (others available on request)
Safety standards: EN/IEC 62109-1, EN/IEC 62109-2, EN 50503, IEC 62116, IEC 60068, IEC 61683
Mains connection standards: IEC61727, VDE-AR-N-4105, VDE 4110, VDE 0126-1-1, BDEW, G59/3, UTE C15-712-1, CEI 0-16, CEI 0-21, RD 661, RD 1699, P.O. 12.3, RD 413, EN-50438-Turkey, EN-50438-Ireland, C10/11, MEA, Resolution No.7, NRS 097-2-1, DEWA
Huawei SUN2000-50KTL-M3 – Notes and explanations
The maximum input voltage is the upper limit of the DC voltage. A higher input DC voltage would probably damage the inverter.
Any DC input voltage outside the operating voltage range may cause the inverter to operate incorrectly.
SUN2000-30~50KTL-M3 raises the potential between PV and ground to above zero by the built-in PID recovery function to resolve module degradation by PID. Supported module types are: P-type (mono, poly), N-type (nPERT, HIT).
Model No. | SUN2000-50KTL-M3 |
Input Data(DC) | |
Max. DC Voltage | 1100 V |
Rated DC Voltage | 600 V |
Min. DC Voltage to Start Feed In | 200 V |
Max. DC Current | 120 A |
MPP(T) Voltage Range | 200~1000 V |
No of MPP Trackers | 4 |
DC Inputs | 8 |
Output Data (AC) | |
Max. AC Power | 55 kW |
Nominal AC Power | 50 kW |
Frequency | 50, 60 Hz |
Power Factor (cosθ) | 1 |
Distortion (THD) | < 3 % |
No of feed-in phases | 3 |
Max. Efficiency | 98.50% |
Euro Efficiency | 98% |
General Data | |
Dimensions (H/W/D) | 530x640x270 mm |
Weight | 49 kg |
Power Consumption at Night | < 5.5 W |
Operating Temperature | -25 ~ +60 ℃ |
Transformer | Transformerless |
Protection Class | IP66 |
Humidity | 0-100 % |
Cooling | Fan |
Max. Altitude | 4000 m |
Interface | RS 485, Ethernet, WLAN |
Display | LED |
Protection Features | |
Protection Features | Anti Island Protection(ENS), Overcurrent Protection, Residual Current Device (RCD), Reverse Polarity Protection, Surge Protection |
Weight | 45 kg |
---|---|
Dimensions | 70 × 70 × 40 cm |
Brand | |
Max PV Input Power(W) |
75000 |
Max PV Input Voltage(V) |
1100 |
Max PV Input Current(A) |
30 |
Start-up Voltage(V) |
200 |
MPPT Voltage Range(V) |
200-1000 |
No. Of MPPT |
4 |
MPPT Efficiency |
98.5% |
Rated AC Input/Output Active Power(W) |
50000 |
Rated Input/Output Grid Frequency/Range |
50Hz/45Hz-55Hz ,60Hz/55Hz-65Hz |
Rated Input/Output Voltage/Range(V) |
230/400V |
Max AC Output Current(A) |
79.8 |
Monitor Mode |
4G ,GPRS ,LAN ,WIFI |
Be the first to review “HUAWEI Smart String Solar Inverter SUN2000-50KTL-M3 50KW 380V Three Phase On-Grid FusionSolar PV solutions for Residential/Carport/Commercial” Cancel reply
Huawei's solar technology, particularly its inverters and energy management systems, is recognized for its advanced features and high efficiency.
Efficiency and Performance
High Efficiency: Huawei inverters typically boast efficiency ratings above 98%, comparable to other top brands like Sungrow. However, Huawei's inverters have a slight edge in performance under partial shading conditions due to their AI-driven Maximum Power Point Tracking (MPPT) technology, which optimizes energy production and consumption effectively.
Durability: Both Huawei and competing brands like Sungrow feature inverters with IP65 ratings, making them resistant to dust and water. Huawei's advanced cooling technology enhances operational reliability, especially in hot climates.
Smart Technology and Monitoring
AI Integration: Huawei inverters are equipped with smart energy management features that utilize AI to optimize energy production and consumption. This is a significant advantage for homeowners looking to maximize self-consumption and reduce grid reliance.
Advanced Monitoring: The FusionSolar app allows users to monitor system performance in real-time, receive alerts, and analyze energy consumption patterns. Huawei’s monitoring capabilities are often praised for their detailed analytics and predictive features, which can preemptively notify users of potential issues.
Compatibility and Versatility
Battery Compatibility: Huawei inverters are designed for seamless integration with various battery systems, making them a popular choice for hybrid solar solutions. This flexibility is crucial for users looking to implement energy storage alongside their solar systems.
Modular Design: Huawei's solar solutions are modular, allowing for easy expansion and scalability, which is beneficial for both residential and commercial applications.
Cost and Value
Competitive Pricing: Huawei's systems are priced approximately 7% higher than some competitors, such as SolaX. This premium reflects their commitment to advanced technology and user-friendly design while remaining competitive in the market.
