Jinko Solar Panels Tiger Neo 54HL4R-B 430-455W N-Type Mono-facial Monocrystalline PV Module All Back For On-Grid Solar Power System
$0.10
The Jinko Solar solar panel is a high-quality, high-efficiency option for residential or commercial solar systems. With bifacial technology with dual glass and N-type M10 (182mm) monocrystalline cells, this panel offers an efficiency of up to 22.36%. Furthermore, its degradation in the first year is less than 1% (it does not present initial degradation by LID or LETID) and during the following 30 years it is less than 0.4%. Jinko Solar also offers a 12-year product and 30-year production warranty, demonstrating its commitment to quality and long-term customer satisfaction.
Jinko Solar Panels Tiger Neo 54HL4R-B 430-455W N-Type Mono-facial Monocrystalline PV Module All Back For On-Grid Solar Power System
The Jinko Solar N type monocrystalline solar panel is an All black module with rectangular cells and a maximum efficiency of 22.02%. It has a 25-year product and 30-year production warranty, which ensures its long-term durability and efficiency. Furthermore, its degradation in the first year is less than 1% and it has an annual degradation of 0.40% for 30 years, which guarantees its constant performance throughout its useful life. With these features, the Jinko Solar solar panel is an excellent choice for residential and commercial solar power systems.
Jinko Tiger Neo 435W Mono All Black Solar Panel – JKM435N-54HL4R-B
Aesthetically pleasing appearance with black frame, well suited for domestic roof top installations with a 25 Year Product Warranty
Unlock the potential of solar energy like never before with the 435W Jinko Solar Panel – JKM435N-54HL4R-B. This cutting-edge solar panel is engineered to provide you with the highest levels of efficiency, durability, and performance, making it the ideal choice for both residential and commercial solar installations.
Key features of the Jinko Tiger Neo 435W Mono All Black Solar Panel:
- Impressive Power Output: With a remarkable power output of 435 watts, this solar panel is a true powerhouse, capable of generating more electricity in a smaller footprint. You’ll need fewer panels to meet your energy needs, which means more space on your roof for other purposes.
- High Efficiency: Jinko Solar is renowned for its commitment to efficiency, and the JKM435N-54HL4R-B is no exception. Thanks to its advanced photovoltaic technology and superior manufacturing processes, it boasts one of the highest conversion efficiencies in the industry. This means you’ll maximize your energy production and enjoy faster payback on your investment.
- Durable Construction: Built to withstand the harshest of environmental conditions, this solar panel features a robust design. It is crafted with high-quality materials, including a corrosion-resistant aluminum frame and tempered glass, ensuring its longevity and resistance to weather, such as rain, snow, and hail.
- Anti-PID Technology: Potential-Induced Degradation (PID) can compromise the performance of solar panels over time. The JKM435N-54HL4R-B is equipped with anti-PID technology, which mitigates the impact of PID, ensuring your solar system remains efficient and reliable for years.
- Low-Light Performance: These panels are optimized for low-light conditions, ensuring they continue to produce electricity even during cloudy days or in the early morning and late evening. This maximizes your energy harvest throughout the day.
- Certified Quality: Jinko Solar is a globally recognized brand known for its stringent quality control processes. The JKM435N-54HL4R-B is backed by various certifications, including IEC, UL, and TUV, ensuring it meets or exceeds international standards for safety and performance.
- Easy Installation: Installing these panels is a breeze, thanks to their standardized dimensions and pre-drilled holes. Whether you’re a professional installer or a DIY enthusiast, you’ll appreciate the simplicity of integrating these panels into your solar system.
- Environmentally Friendly: By choosing the Jinko Solar Panel – JKM435N-54HL4R-B, you’re not only reducing your carbon footprint but also contributing to a more sustainable future. Solar energy is clean, renewable, and helps combat climate change.
Upgrade your solar system to the next level with the 435W Jinko Solar Panel – JKM435N-54HL4R-B. Experience the benefits of higher energy output, greater efficiency, and long-lasting durability. Invest in a brighter and more sustainable future with Jinko Solar.
| Type | Monocrystalline | |||||
| Model No. | JKM430N-54HL4R-B | JKM435N-54HL4R-B | JKM440N-54HL4R-B | JKM445N-54HL4R-B | JKM450N-54HL4R-B | JKM455N-54HL4R-B |
| Warranty | ||||||
| Product Warranty | 25 Years | |||||
| Power Warranty | 30 Years of 87.4% Output Power | |||||
| Electrical Data at STC | ||||||
| Maximum Power (Pmax) | 430 Wp | 435 Wp | 440 Wp | 445 Wp | 450 Wp | 455 Wp |
| Voltage at Maximum Power (Vmpp) | 32.58 V | 32.78 V | 32.99 V | 33.19 V | 33.39 V | 33.58 V |
| Current at Maximum Power (Impp) | 13.2 A | 13.27 A | 13.34 A | 13.41 A | 13.48 A | 13.55 A |
| Open Circuit Voltage (Voc) | 39.16 V | 39.36 V | 39.57 V | 39.77 V | 39.97 V | 40.17 V |
| Short Circuit Current (Isc) | 13.65 A | 13.72 A | 13.8 A | 13.87 A | 13.94 A | 14.01 A |
| Panel Efficiency | 21.52% | 21.77% | 22.02% | 22.27% | 22.52% | 22.77% |
| Power Tolerance (Positive) | 3% | 3% | 3% | 3% | 3% | 3% |
| Standard Test Conditions (STC): air mass AM 1.5, irradiance 1000W/m2, cell temperature 25°C | ||||||
| Thermal Ratings | ||||||
| Operating Temperature Range | -40~70 °C | |||||
| Temperature Coefficient of Pmax | -0.29 %/°C | |||||
| Temperature Coefficient of Voc | -0.25 %/°C | |||||
| Temperature Coefficient of Isc | 0.045 %/°C | |||||
| Maximum Ratings | ||||||
| Maximum System Voltage | 1000 V | |||||
| Series Fuse Rating | 25 A | |||||
| Material Data | ||||||
| Panel Dimension (H/W/D) | 1762x1134x30 mm | |||||
| Weight | 21 kg | |||||
| Cell Number | 108 | |||||
| Glass Type | Anti-reflection Coating, Tempered | |||||
| Glass Thickness | 3.2 mm | |||||
| Frame Type | Anodized Aluminium, Black | |||||
| Junction Box Protection Class | IP 68 | |||||
| Cable Crossection | 4 mm2 | |||||
| Weight | 22 kg |
|---|---|
| Dimensions | 180 × 115 × 3 cm |
| Brand | |
| Cables |
4.0 mm |
| Encapsulant Material |
POE/EVA |
| J-Box |
IP68 |
| Maximum Power |
450 |
| Number Of Solar Cells |
108 |
| Solar Cells |
N-type Monocrystalline |
| Module Dimension(mm) |
1762x1134x30 |
| Backsheet |
2.0mm Heat Strengthened Glass |
| Front Glass |
2.0mm AR Coated Heat Strengthened Glass |
| Vmp(V) |
40.23 |
| Imp(A) |
13.32 |
| Backside Power |
N/A |
| Connector |
MC4 |
| Weight[kg] |
21 |
JinkoSolar Holding Co., Ltd. is one of the largest and most innovative solar module manufacturers globally. Founded in 2006, the company has established a strong presence in the solar industry, recognized for its commitment to technological innovation and high-quality solar products.
Key Achievements and Market Position
AAA Rating: JinkoSolar has consistently topped the PV Tech ModuleTech Bankability Report, earning a “AAA” rating, which highlights its leadership in manufacturing excellence, reliable quality, and strong financial performance.
Market Share: As of 2023, JinkoSolar held approximately 15% of the global solar module market, making it the largest manufacturer by shipment volume, with total module shipments exceeding 210 GW.
Financial Performance: In 2023, JinkoSolar reported total revenue of RMB 118.68 billion, a 43.55% increase year-over-year, and a net profit attributable to shareholders of RMB 7.44 billion, reflecting a 153.2% increase year-over-year.
Technological Innovations
N-type Technology: JinkoSolar is a leader in N-type solar technology, particularly with its Tiger Neo modules, which utilize advanced N-type monocrystalline solar cells. This technology allows for higher efficiency and better performance in low-light conditions.
Record Efficiency: The company has achieved significant milestones in solar cell efficiency, including a record conversion efficiency of 33.24% for its N-type TOPCon based perovskite tandem solar cells and an average mass production efficiency of 26.1% for N-type TOPCon cells.
Patents: JinkoSolar holds 330 patents related to TOPCon technology, underscoring its commitment to innovation in the photovoltaic sector.
Product Offerings
Tiger Neo Series: The Tiger Neo N-type solar panels are designed for high performance and efficiency, featuring a half-cut cell design that improves energy output and reduces losses. The JKM585N-72HL4-V model, for example, has a power output of 585W and is optimized for various installation conditions.
Global Distribution: JinkoSolar distributes its products to a wide range of markets, including the United States, Europe, Asia, and Africa, with a strong focus on utility-scale, commercial, and residential applications.
Future Outlook
Growth Projections: JinkoSolar anticipates a growth rate of 25% to 30% in global photovoltaic demand for 2024, with expectations to ship between 100 GW to 110 GW of solar modules throughout the year.
Strategic Initiatives: The company is focusing on optimizing its supply chain and production processes to manage costs effectively while addressing market challenges such as oversupply and pricing pressures.
