Jinko Solar Panels Tiger Neo 54HL4R-BDB 425-445W N-Type Bifacial Monocrystalline PV Module Dual Glass PV Module With All Back For On-Grid Solar Power System
$0.10
The Jinko Solar solar panel is a high-quality, high-efficiency option for residential or commercial solar systems. With bifacial technology with dual glass and N-type M10 (182mm) monocrystalline cells, this panel offers an efficiency of up to 22.36%. Furthermore, its degradation in the first year is less than 1% (it does not present initial degradation by LID or LETID) and during the following 30 years it is less than 0.4%. Jinko Solar also offers a 12-year product and 30-year production warranty, demonstrating its commitment to quality and long-term customer satisfaction.
Jinko Solar Panels Tiger Neo 54HL4R-BDB 425-445W N-Type Bifacial Monocrystalline PV Module Dual Glass PV Module With All Back For On-Grid Solar Power System
- 108 Monocrystalline – N-type (2 x 54)
- Frame made of anodized aluminum alloy
- 25-year product warranty
- 30-year linear power warranty
- MBB technology: Enhanced light collection and current collection to increase module performance and reliability
- Hot 2.0 Technology: N-type module with Hot 2.0 technology demonstrates improved reliability and reduced LID/LETID
Jinko Tiger Neo 445 Wp bifacial N-Type Glass-Glass Solar Panels Fullblack 54HL4R-BDB
With the Tiger Neo 54HL4R-BDB, Jinko Solar Panels have launched a highly efficient and powerful all-black N-type solar pv module for private and commercial photovoltaic systems. With a rated output of up to 445 watts, bifacial energy generation on both sides and an efficiency of up to 22.27%, the module demonstrates its outstanding performance even in diffuse light conditions, thus ensuring excellent energy yield. In addition, the stable double glass design and resistance to adverse weather conditions make it the ideal choice for anyone who values performance, quality and reliability.
Features:
Better light trapping and current collection to improve module power output and reliability thanks to SMBB technology
Reduced power degradation due to N-type cells with Hot 2.0 technology
Minimises the risk of performance degradation due to potential-induced degradation (PID)
Two-sided energy generation thanks to bifaciality
Full black look for a more appealing aesthetic, especially on darker roofs
| Type | Monocrystalline | ||||
| Model No. | 425W | 430W | 435W | 440W | 445W |
| Warranty | |||||
| Product Warranty | 25 Years | ||||
| Power Warranty | 30 Years of 87.4% Output Power | ||||
| Electrical Data at STC | |||||
| Maximum Power (Pmax) | 425 Wp | 430 Wp | 435 Wp | 440 Wp | 445 Wp |
| Voltage at Maximum Power (Vmpp) | 32.9 V | 33.08 V | 33.26 V | 33.44 V | 33.61 V |
| Current at Maximum Power (Impp) | 12.92 A | 13 A | 13.08 A | 13.16 A | 13.24 A |
| Open Circuit Voltage (Voc) | 39.23 V | 39.43 V | 39.63 V | 39.83 V | 40.03 V |
| Short Circuit Current (Isc) | 13.77 A | 13.84 A | 13.91 A | 13.98 A | 14.05 A |
| Panel Efficiency | 21.27% | 21.52% | 21.77% | 22.02% | 22.27% |
| Power Tolerance (Positive) | 3% | 3% | 3% | 3% | 3% |
| Standard Test Conditions (STC): air mass AM 1.5, irradiance 1000W/m2, cell temperature 25°C | |||||
| Electrical Data at NOCT | |||||
| Maximum Power (Pmax) | 320 Wp | 324 Wp | 328 Wp | 332 Wp | 335 Wp |
| Voltage at Maximum Power (Vmpp) | 30.33 V | 30.51 V | 30.69 V | 30.9 V | 31.11 V |
| Current at Maximum Power (Impp) | 10.56 A | 10.62 A | 10.68 A | 10.73 A | 10.78 A |
| Open Circuit Voltage (Voc) | 37.26 V | 37.45 V | 37.64 V | 37.83 V | 38.02 V |
| Short Circuit Current (Isc) | 11.12 A | 11.17 A | 11.23 A | 11.28 A | 11.34 A |
| Temperature | 45±2 °C | ||||
| Nominal Operating Cell Temperature (NOCT): 800W/m2, AM 1.5, windspeed 1m/s,ambient temperature 20°C | |||||
| Thermal Ratings | |||||
| Operating Temperature Range | -40~85 °C | ||||
| Temperature Coefficient of Pmax | -0.29 %/°C | ||||
| Temperature Coefficient of Voc | -0.25 %/°C | ||||
| Temperature Coefficient of Isc | 0.045 %/°C | ||||
| Maximum Ratings | |||||
| Maximum System Voltage | 1500 V | ||||
| Series Fuse Rating | 30 A | ||||
| Material Data | |||||
| Panel Dimension (H/W/D) | 1762x1134x30 mm | ||||
| Weight | 25.4 kg | ||||
| Cell Number | 108 | ||||
| Glass Type | Anti-reflection Coating | ||||
| Glass Thickness | 2 mm | ||||
| Frame Type | Anodized Aluminium, Black | ||||
| Junction Box Protection Class | IP 68 | ||||
| Cable Crossection | 4 mm2 | ||||
| Weight | 25.4 kg |
|---|---|
| Dimensions | 180 × 115 × 3 cm |
| Brand | |
| Cables |
4.0 mm |
| Encapsulant Material |
POE/EVA |
| J-Box |
IP68 |
| Maximum Power |
445 |
| Number Of Solar Cells |
108 |
| Solar Cells |
N-type Monocrystalline |
| Module Dimension(mm) |
1722x1134x30 |
| Backsheet |
1.6mm semi-tempered glass |
| Front Glass |
3.2mm AR Coated Heat Strengthened Glass |
| Vmp(V) |
36.79 |
| Imp(A) |
13.59 |
| Backside Power |
N/A |
| Connector |
MC4 |
| Weight[kg] |
22.5 |
JinkoSolar Holding Co., Ltd. is one of the largest and most innovative solar module manufacturers globally. Founded in 2006, the company has established a strong presence in the solar industry, recognized for its commitment to technological innovation and high-quality solar products.
Key Achievements and Market Position
AAA Rating: JinkoSolar has consistently topped the PV Tech ModuleTech Bankability Report, earning a “AAA” rating, which highlights its leadership in manufacturing excellence, reliable quality, and strong financial performance.
Market Share: As of 2023, JinkoSolar held approximately 15% of the global solar module market, making it the largest manufacturer by shipment volume, with total module shipments exceeding 210 GW.
Financial Performance: In 2023, JinkoSolar reported total revenue of RMB 118.68 billion, a 43.55% increase year-over-year, and a net profit attributable to shareholders of RMB 7.44 billion, reflecting a 153.2% increase year-over-year.
Technological Innovations
N-type Technology: JinkoSolar is a leader in N-type solar technology, particularly with its Tiger Neo modules, which utilize advanced N-type monocrystalline solar cells. This technology allows for higher efficiency and better performance in low-light conditions.
Record Efficiency: The company has achieved significant milestones in solar cell efficiency, including a record conversion efficiency of 33.24% for its N-type TOPCon based perovskite tandem solar cells and an average mass production efficiency of 26.1% for N-type TOPCon cells.
Patents: JinkoSolar holds 330 patents related to TOPCon technology, underscoring its commitment to innovation in the photovoltaic sector.
Product Offerings
Tiger Neo Series: The Tiger Neo N-type solar panels are designed for high performance and efficiency, featuring a half-cut cell design that improves energy output and reduces losses. The JKM585N-72HL4-V model, for example, has a power output of 585W and is optimized for various installation conditions.
Global Distribution: JinkoSolar distributes its products to a wide range of markets, including the United States, Europe, Asia, and Africa, with a strong focus on utility-scale, commercial, and residential applications.
Future Outlook
Growth Projections: JinkoSolar anticipates a growth rate of 25% to 30% in global photovoltaic demand for 2024, with expectations to ship between 100 GW to 110 GW of solar modules throughout the year.
Strategic Initiatives: The company is focusing on optimizing its supply chain and production processes to manage costs effectively while addressing market challenges such as oversupply and pricing pressures.
