Solplanet On-Grid Solar Inverter LT-G2 series ASW10K-LT-G2 380V Three Phase Solar Solution For Residential Solar Energy System
$415.00
Industry-leading high-efficiency solar inverters
ASW 8K LT-G2 | ASW 10K LT-G2 | ASW 12K LT-G2 | ASW 15K LT-G2 | ASW 17K LT-G2 |ASW 20K LT-G2
Benchmark performance for smaller systems
The ASW 8-20K LT-G2 series is our line of benchmark three phase solar inverters designed for use in small decentralized residential, commercial, and industrial systems. These high-performance and high-delivery inverters are extremely easy to install and commission and are designed to be reliable and low-maintenance.
The ASW 8-20K LT-G2 solar inverters feature a sleek design that is compact, wall-mountable, and IP66-rated, making them weatherproof and extremely durable. They have a wide MPP voltage range with a possible 150% oversizing of the PV array for flexibility and efficiency under a variety of conditions. Do you need an inverter that can power an energy-hungry system? The ASW 8-20K LT-G2 series inverters feature a maximum input current of 13A per string making them a perfect pairing for bi-facial and large-area PV arrays.
Main Benefits
- IP66-rated design for reliable outdoor use
- Maximum 13A input current per string
- Wide MPP voltage range 150 – 1000V
- Quick and easy installation using standard tools
- Easy commissioning and monitoring with Solplanet app
- Built-in Type II DC & AC surge protection
Key Features
Reliable
The ASW 8-20K LT-G2 series was designed in accordance with international quality and safety standards and is a robust family of extremely reliable solar inverters. The IP66 certification rating also means these inverters will maintain their reliability in a wide range of environmental conditions. From a purely technical angle, the DC reverse polarity protection, AC sensitive residual current monitoring, and built-in surge protection functions ensure reliable and safe long-term operation.
Powerful
Our ASW 8-20K LT-G2 series solar inverters are designed for power. A maximum DC input of 13A and a wide MPP voltage range ensure highly optimised energy performance for bi-facial and large-area PV modules. These dynamic solar inverters also allow up to 150% oversizing of the attached PV array, making them perfect for residential rooftop solar installations that vary greatly in their design, scale, and purpose.
Installation & Monitoring
The ASW 8-20K LT-G2 series is designed to be installed quickly and easily with standard tools and the Phoenix Contact DC connectors make these inverters compatible with a wide range of solar panels. Optional Plug & Play and 4G dongles connect them to the internet and allow up to five to be monitored by Solplanet’s user-friendly mobile application. Users can view real-time solar installation data, configure their inverters, and receive system alerts, right in the palm of their hand.
| Technical Datasheet | ASW8K-LT-G2 | ASW 10K-LT-G2 | ASW 12K-LT-G2 | ASW 15K-LT-G2 | ASW 17K-LT-G2 | ASW 20K-LT-G2 | |
| Input (DC) | Max. PV array power | 12000 Wp STC | 15000 Wp STC | 18000 Wp STC | 22500 Wp STC | 25500 Wp STC | 30000 Wp STC |
| Max. input voltage | 1100 V | ||||||
| MPP voltage range / rated input voltage | 150 V to 1000 V / 630 V | ||||||
| Min. input voltage | 125 V | ||||||
| Initial. feed-in voltage | 150 V | ||||||
| Max. operating input current | 26 A / 13 A | 26 A / 13 A | 26 A / 26 A | 26A/26A | 26A/26A | 26A/26A | |
| Max. short circuit current | 40 A / 20 A | 40 A / 20 A | 40 A / 40 A | 40A /40 A | 40A/40A | 40A/40A | |
| No. of independent MPPT inputs /strings per MPPT input | 2 / A:1;B:1 | 2 / A:1;B:1 | 2 / A:2;B:1 | 2/A:2;B:1 | 2 / A:2;B:2 | 2 / A:2;B:2 | |
| Output (AC) | Rated active power | 8000 W | 10000 W | 12000 W | 15000 W | 17000 W | 20000 W |
| Rated apparent power | 8000 VA | 10000 VA | 12000 VA | 15000 VA | 17000 VA | 20000 VA | |
| Max. apparent power | 8000 VA | 10000 VA | 12000 VA | 15000 VA | 17000 VA | 20000 VA | |
| AC nominal voltage | 220 V / 380 V | ||||||
| 230 V / 400 V | |||||||
| 240 V / 415 V | |||||||
| AC voltage range | 160 V to 300 V | ||||||
| AC grid frequency / range | 50 Hz / 45 Hz to 55 Hz | ||||||
| 60 Hz / 55 Hz to 65 Hz | |||||||
| Max. output current | 12.8 A | 16 A | 19.1 A | 24 A | 27.1 A | 31.9 A | |
| Adjustable power factor range | 0.8 leading to 0.8 lagging | ||||||
| Feed-in phases | 3 / 3-N-PE | ||||||
| Harmonic distortion (THD) at rated output | <3 % | ||||||
| Efciency & Protection | Max. efciency / European efciency | 98.6 % / 98.2 % | |||||
| DC Switch | ● | ||||||
| Ground fault monitoring / grid monitoring | ● / ● | ||||||
| DC reverse polarity protection / AC short circuit protection | ● / ● | ||||||
| All-pole-sensitive residual-current monitoring unit | ● | ||||||
| Anti-Islanding protection | ● | ||||||
| Surge protection | ● / Type II | ||||||
| Protection class (according to IEC 62109-1) / | I / AC: III; DC: II | ||||||
| overvoltage category (according to IEC 62109-1) | |||||||
| General data | Dimensions (W / H / D) | 503 / 435 / 183 mm | |||||
| Weight | 16 kg | 17 kg | |||||
| Operating temperature range | -25°C … +60°C | ||||||
| Self-consumption (at night) | < 1 W | ||||||
| Topology | Non-isolated | ||||||
| Cooling concept | Natural convection | Active cooling | |||||
| Degree of protection (according to IEC 60529) | IP66 | ||||||
| Climatic category (according to IEC 60721-3-4) | 4K4H | ||||||
| Max. permissible value for relative humidity (non-condensing) | 100% | ||||||
| Max. operating altitude | 3000 m | ||||||
| Features | DC connection | Plug-in connector | |||||
| AC connection | Plug-in connector | ||||||
| Mounting type | Wall-mount bracket | ||||||
| LED indicators (Status / Fault / Communication) | ● | ||||||
| Communication interface | ●/●/●/○ | ||||||
| (RS485 /Wi-Fi/ LAN /4G) | |||||||
| Country of manufacture | China | ||||||
| Certifcates and approvals (more available on request) | CE, EN50549, IEC62109, IEC62116, IEC61727, IEC61683, IEC60068, IEC61000, AS/NZS4777, C10/C11 | ||||||
| Weight | 20 kg |
|---|---|
| Dimensions | 60 × 50 × 30 cm |
| Brand | |
| Max PV Input Power(W) |
15000 |
| Max PV Input Voltage(V) |
1100 |
| Max PV Input Current(A) |
13 |
| Start-up Voltage(V) |
150 |
| MPPT Voltage Range(V) |
150-1000 |
| No. Of MPPT |
2/1+1 |
| MPPT Efficiency |
98.6% |
| Rated AC Input/Output Active Power(W) |
10000 |
| Rated Input/Output Grid Frequency/Range |
50Hz/45Hz-55Hz ,60Hz/55Hz-65Hz |
| Rated Input/Output Voltage/Range(V) |
380/400/415 |
| Max AC Output Current(A) |
16 |
| Monitor Mode |
4G ,GPRS ,LAN ,WIFI |
Solplanet is a brand that specializes in solar inverters and energy solutions, focusing on providing high-quality products for residential, commercial, and utility-scale solar applications.
Company Overview:
Founded: Solplanet is a relatively new brand that emerged from the established solar technology company AISWEI, which has a strong background in the solar industry.
Headquarters: The brand is based in China but aims to serve a global market.
Key Products:
Solar Inverters:
Solplanet offers a range of solar inverters, including string inverters and hybrid inverters designed for various applications.
Their products are known for high efficiency, reliability, and advanced features to maximize energy production.
Energy Storage Solutions:
The brand is also involved in developing energy storage systems that complement solar installations, allowing for optimized energy management and usage.
Key Features:
High Efficiency: Solplanet inverters typically boast high conversion efficiencies, often exceeding 98%, which helps maximize energy yield from solar panels.
Smart Monitoring: Many of their inverters come equipped with monitoring capabilities, enabling users to track performance and diagnose issues in real-time through mobile apps or web interfaces.
User-Friendly Design: Solplanet products are designed for easy installation and maintenance, making them suitable for both professional installers and DIY enthusiasts.
Market Presence:
Solplanet aims to establish a strong presence in the global solar market, focusing on regions with high solar energy potential.
The brand emphasizes quality and performance, aiming to compete with other established solar inverter manufacturers.
Commitment to Sustainability:
Solplanet is dedicated to promoting renewable energy solutions, contributing to the global shift toward sustainable energy practices.
