Sungrow Hybrid Solar Inverter SH6RS 6kW Single Phase Solution For Residential Solar Energy System Compatible 80-460V Lithium Battery
$1,030.00
Benefits of the Sungrow 1PH Hybrid Solar Inverter 3.6kW Optimizer Ready:
- Compatible with high-power PV modules and bifacial modules
- Dual MPPT for optimal energy harvesting
- IP65-rated for outdoor and indoor use
- Optimizer ready for enhanced performance
- Integrated battery support with a wide voltage range of 80~460 V
Sungrow Hybrid Solar Inverter SH6RS 6kW Single Phase Solution For Residential Solar Energy System Compatible 80-460V Lithium Battery
The Sungrow hybrid solar inverters from the SH series offer smart energy management, an emergency power function and are also quick to install. The SH series supports batteries from various manufacturers and the wide battery voltage range makes the inverter flexible to use.
Offering a wide range of solutions and services, Sungrow is committed to providing clean power for all and is steadfast in its efforts to become the global leader in clean power conversion technology.
The Sungrow SH6RS hybrid solar inverter is perfect for residential installations. It’s lightweight and compact build along with plug and play installation makes it easy to carry out installations. It’s also built to be ideal for new or retrofit installations.
The residential single phase hybrid solar inverter can be connected to the following batteries:
Sungrow: SBR096-SBR192 (3-6 battery modules)
The Sungrow 3.0/3.6/4.0/5.0/6.0RS is an advanced and intelligent residential single phase hybrid solar inverter.
Flexible application
- 80 – 460 V wide battery voltage range
- Ideal for both retrofitting and new installations
- Built-in smart PID recovery function
Energy independence
- Seamless transition to backup mode, for protection against power outages
- Fast Charging or discharging, enabling higher self-consumption results
- Built-in EMS with advancedcustomization
User friendly setup
- Plug and play installation
- iSolarCloud monitoring available on app and web
- Lightweight and compact, optimized for heat dissipation
Smart management
- Real time data (10 seconds refresh sample)
- 24/7 live monitoring both online and with integrated display
- Online IV curve scan and diagnosis
Sungrow stands for simplicity and quality. For 25 years, the innovative company has been providing high-quality products that are easy to install. The company produces sustainably and operates in more than 150 countries
| Type designation | SG3.0RS | SG3.6RS | SG4.0RS | SG5.0RS | SG6.0RS |
| Input (DC) | |||||
| Recommended max. PV input power | 4.5 kWp | 5.4 kWp | 6 kWp | 7.5 kWp | 9 kWp |
| Max. PV input voltage | 600 V | ||||
| Min. operating PV voltage / Start-up input voltage | 40 V / 50 V | ||||
| Rated PV input voltage | 360 V | ||||
| MPP voltage range | 40 – 560 V | ||||
| No. of independent MPP inputs | 2 | ||||
| Default No. of PV strings per MPPT | 1 | ||||
| Max. PV input current | 32 A (16 A / 16 A) | ||||
| Max. DC short-circuit current | 40 A (20 A / 20 A) | ||||
| Output (AC) | |||||
| Rated AC output power | 3000 W | 3680 W | 4000 W | 5000 W* | 6000 W |
| Max. AC Output power | 3000 VA | 3680 VA | 4000 VA | 5000 VA* | 6000 VA |
| Rated AC output current (at 230 V) | 13.1 A | 16 A | 17.4 A | 21.8 A** | 26.1 A |
| Max. AC output current | 13.7 A | 16 A | 18.2 A | 22.8 A** | 27.3 A |
| Rated AC voltage | 220 / 230 / 240 V | ||||
| AC voltage range | 154 – 276 V | ||||
| Rated grid frequency / Grid frequency range | 50 Hz / 45 – 55 Hz, 60 Hz / 55 – 65 Hz | ||||
| Harmonic (THD) | < 3 % (at rated power) | ||||
| Power factor at rated power / Adjustable power factor | > 0.99 / 0.8 leading – 0.8 lagging | ||||
| Feed-in phases / Connection phases | 1/1 | ||||
| Efficiency | |||||
| Max. efficiency | 97.90% | ||||
| European efficiency | 97.00% | 97.00% | 97.20% | 97.30% | 97.50% |
| Protection | |||||
| Grid monitoring | Yes | ||||
| DC reverse polarity protection | Yes | ||||
| AC short-circuit protection | Yes | ||||
| Leakage current protection | Yes | ||||
| Surge Protection | DC type II / AC type II | ||||
| DC switch | Yes | ||||
| PV string current monitoring | Yes | ||||
| Arc fault circuit interrupter (AFCI) | Optional | ||||
| PID recovery function | Yes | ||||
| General Data | |||||
| Dimensions (W*H*D) | 410 * 270* 150 mm | ||||
| Weight | 10 kg | ||||
| Mounting method | Wall-mounting bracket | ||||
| Topology | Transformerless | ||||
| Degree of protection | IP65 | ||||
| Operating ambient temperature range | -25 to 60 ℃ | ||||
| Allowable relative humidity range (non-condensing) | 0 – 100 % | ||||
| Cooling method | Natural cooling | ||||
| Max. operating altitude | 4000 m | ||||
| Display | LED digital display & LED indicator | ||||
| Communication | Ethernet / WLAN / RS485 / DI (Ripple control & DRM) | ||||
| DC connection type | MC4 (Max. 6 mm²) | ||||
| AC connection type | Plug and play connector (Max. 6 mm²) | ||||
| Grid compliance | IEC/EN62109-1/2, IEC/EN62116, IEC/EN61727, IEC/EN61000-6-2/3, EN50549-1, | ||||
| AS4777.2, ABNT NBR 16149, ABNT NBR 16150, UNE 217002:2020, NTS V2 TypeA, | |||||
| CEI 0-21:2019, VDE0126-1-1/A1 (VFR-2019), UTE C15-712, C10/11, G98/G99 | |||||
| Grid Support | Active & reactive power control and power ramp rate control | ||||
| Weight | 12 kg |
|---|---|
| Dimensions | 50 × 40 × 30 cm |
| Brand | |
| Battery Type |
Lithium-ion |
| Max. Charging Current(A) |
30 |
| Battery Voltage Range(V) |
80-460 |
| Max PV Input Power(W) |
13000 |
| Max PV Input Voltage(V) |
600 |
| MPPT Voltage Range(V) |
40-560 |
| No. Of MPPT |
2/1+1 |
| Number of battery input |
1 |
| Rated AC Input/Output Active Power(W) |
6000 |
| Rated Input/Output Grid Frequency/Range |
50Hz/45Hz-55Hz ,60Hz/55Hz-65Hz |
| Rated Input/Output Voltage/Range(V) |
220V/230V |
