Trina Solar Panels Vertex S+ Mono-facial TSM-NEG9R.28 430-455W 144 Cells N Type Monocrystalline Dual Glass PV Module For Solar Power System
$0.10
Trina Solar is the leading global manufacturer of high-quality photovoltaic modules and advanced energy solutions. The company has been on the market since 1997. As part of its activities, it constantly conducts research in new energy products and the development of innovative technologies. Trina Solar’s business includes photovoltaic project development, financing, design, construction and management, and comprehensive system integration solutions for customers. The company has traditionally been at the forefront of solar energy innovation and holds more than 1,000 patents. The company is also ranked Tier 1 by Bloomberg.
SKU:
TSM-NEG9R.28
Categories: For On-Grid, Solar Panels
Tags: Jinko Solar Panel, Solar Panels, solar panels for sale
Trina Solar Panels Vertex S+ Bifacial TSM-NEG9R.28 430-455W 144 Cells N Type Monocrystalline Dual Glass PV Module For Solar Power System
The Trina Vertex S+ 450W TSM-450-NEG9R.28 Black Frame half-cell glass-glass solar panels combines state-of-the-art technologies, including high-density cell connection and multi-busbar technology, with excellent low-light performance and double-glass construction for maximum reliability.It is specially designed for high compatibility with current inverters and mounting systems, facilitates installation due to its low weight and optimises transport costs.With a product guarantee of 25 years and a performance guarantee of 30 years, supported by N-type technology with minimal degradation, it offers exceptional long-term investment security and is an excellent choice for sustainable energy projects.
N-TYPE I-TOPCON CELL TECHNOLOGY
This advanced cell technology optimises the conversion efficiency of sunlight into electrical energy.It reduces conduction losses and improves the module’s performance under different lighting conditions, resulting in a higher energy yield over the product’s service life.
Double-glazed construction
The double-glass construction improves the longevity of the solar panels by providing optimum protection against environmental influences such as moisture and mechanical stress.This robust design ensures an extended service life and guarantees long-term efficiency and reliability in energy generation.
The monocrystalline photovoltaic solar panels TSM-455-NEG9R.28 from the Vertex S+ series with 455 W output using modern n-type cell technology combines high performance with impressive durability. The product is perfect for both residential and commercial photovoltaic installations.
Module characteristics:
High module efficiency of 22.8%
Product has a 25-year warranty
Cells in n-type i-TOPCon technology
The module shows excellent resistance to fire and harsh weather conditions due to the double glass on both sides of the module.
The multi-busbar technology (MBB) used in the model results in a lower risk of micro-breaks, slower degradation of the module, as well as lower losses
Linear power guarantee for a period of 30 years. Power degradation in 1 year <1%, subsequent years 0.4% and after 30 years power at 87.4% of the original value
Power tolerance 0/+5 W
The solar panels are compatible with inverters, optimisers and mounting systems from the most reputable manufacturers.
Type | Monocrystalline | |||||
Model No. | 430W | 435W | 440W | 445W | 450W | 455W |
Warranty | ||||||
Product Warranty | 15 Years | |||||
Power Warranty | 30 Years of 87.4% Output Power | |||||
Electrical Data at STC | ||||||
Maximum Power (Pmax) | 430 Wp | 435 Wp | 440 Wp | 445 Wp | 450 Wp | 455 Wp |
Voltage at Maximum Power (Vmpp) | 43.2 V | 43.6 V | 44 V | 44.3 V | 44.6 V | 45 V |
Current at Maximum Power (Impp) | 9.96 A | 9.99 A | 10.01 A | 10.05 A | 10.09 A | 10.11 A |
Open Circuit Voltage (Voc) | 51.4 V | 51.8 V | 52.2 V | 52.6 V | 52.9 V | 53.4 V |
Short Circuit Current (Isc) | 10.59 A | 10.64 A | 10.67 A | 10.71 A | 10.74 A | 10.77 A |
Panel Efficiency | 21.50% | 21.80% | 22% | 22.30% | 22.50% | 22.80% |
Power Tolerance (Positive) | 1% | 1% | 1% | 1% | 1% | 1% |
Standard Test Conditions (STC): air mass AM 1.5, irradiance 1000W/m2, cell temperature 25°C | ||||||
Electrical Data at NOCT | ||||||
Maximum Power (Pmax) | 328 Wp | 332 Wp | 335 Wp | 339 Wp | 343 Wp | 348 Wp |
Voltage at Maximum Power (Vmpp) | 40.5 V | 40.8 V | 41.1 V | 41.4 V | 41.7 V | 42.3 V |
Current at Maximum Power (Impp) | 8.11 A | 8.15 A | 8.17 A | 8.2 A | 8.24 A | 8.22 A |
Open Circuit Voltage (Voc) | 48.8 V | 49.2 V | 49.5 V | 49.9 V | 50.2 V | 50.6 V |
Short Circuit Current (Isc) | 8.53 A | 8.57 A | 8.6 A | 8.63 A | 8.65 A | 8.68 A |
Temperature | 43±2 °C | |||||
Nominal Operating Cell Temperature (NOCT): 800W/m2, AM 1.5, windspeed 1m/s,ambient temperature 20°C | ||||||
Thermal Ratings | ||||||
Operating Temperature Range | -40~85 °C | |||||
Temperature Coefficient of Pmax | -0.29 %/°C | |||||
Temperature Coefficient of Voc | -0.24 %/°C | |||||
Temperature Coefficient of Isc | 0.04 %/°C | |||||
Maximum Ratings | ||||||
Maximum System Voltage | 1500 V | |||||
Series Fuse Rating | 25 A | |||||
Material Data | ||||||
Panel Dimension (H/W/D) | 1762x1134x30 mm | |||||
Weight | 21.8 kg | |||||
Cell Number | 144 | |||||
Glass Type | Anti-reflection Coating | |||||
Glass Thickness | 1.6 mm | |||||
Encapsulant Type | EVA | |||||
Frame Type | Anodized Aluminium | |||||
Junction Box Protection Class | IP 68 | |||||
Connector Type | MC4 | |||||
Cable Crossection | 4 mm2 |
Weight | 22 kg |
---|---|
Dimensions | 180 × 115 × 3 cm |
Brand | |
Cables |
4.0 mm |
Encapsulant Material |
POE/EVA |
J-Box |
IP68 |
Maximum Power |
450 |
Number Of Solar Cells |
144 |
Solar Cells |
N-type Monocrystalline |
Module Dimension(mm) |
1762x1134x30 |
Backsheet |
1.6mm semi-tempered glass |
Front Glass |
2.0mm AR Coated Heat Strengthened Glass |
Vmp(V) |
44.6 |
Imp(A) |
10.09 |
Backside Power |
N/A |
Connector |
MC4 |
Weight[kg] |
21.6 |
