Hoymiles Microinverter HMS-400-1T-NA 400W 230V Single-Phase Solar Inverter For On-grid Residential PV System/Commercial PV Rooftops

Hoymiles Microinverter HMS-400-1T-NA 400W 230V Single-Phase Solar Inverter For On-grid Residential PV System/Commercial PV Rooftops

Hoymiles solar inverter HMS-400-NA series is the new 1-in-1 microinverter for solar panels, and its model is for North America.
Each microinverter in the HMS-400-NA series is designed to be connected to a single solar panel, offering remarkable versatility for a wide range of solar applications. This feature makes the HMS-400-NA series one of the most flexible solar solutions. With a maximum DC voltage of 65 volts, the Hoymiles microinverter is a PV Rapid Shutdown Equipment and conforms with NEC-2017 and NEC-2020 Article 690.12 and CEC-2021 Sec 64-218.
Hoymiles HMS-400-NA series has more stable communication with Hoymiles gateway DTU for its new Sub-1G wireless solution.

Hoymiles new microinverter HMS-400-1T-NA is suitable for high-powered solar panels, which rank among the highest for 1-in-1 microinverters. Each microinverter can be connected to one panel and used in various applications, making it one of the most flexible solar solutions. With a maximum DC voltage of 65 volts, the Hoymiles microinverter is a PV Rapid Shutdown Equipment and conforms with NEC-2017 and NEC-2020 Article 690.12 and CEC-2021 Sec 64-218.

Key Features

• Easy installation, just plug and play
• High-powered microinverter with superior performance
• 1-in-1 design enables the most flexible application
• Safer for rooftop solar stations with PV rapid shutdown compliance
• Sub-1G wireless solution allows stable communication
• With Reactive Power Control, compliant with UL1741, IEEE 1547, UL1741 SB
• Compliant with U.S. NEC-2017&NEC-2020 690.12 Rapid shutdown
• High reliability: NEMA 6( IP67 ) enclosure

Product Specification
Input Data

• Maximum Input Voltage: 65V
• MPPT Voltage Range: 16~60V
• Maximum Input Current: 12.5A
• Number of MPPTs: 1
• Number of inputs per MPPT: 1

Output Data

• Peak output power(VA): 400
• Max. continuous output power(VA): 360
• Maximum continuous output current(A): 1.5 / 1.73
• Maximum units per 10AWG branch:  16 / 13

Efficiency

• CEC peak efficiency: 96.7%
• Nominal MPPT efficiency: 99.8%

Mechanical Data

• Dimensions (W * H * D):  7.17 * 6.46 * 1.18 inches (182* 164* 30 mm )
• Weight: 3.86 lbs ( 1.5kg )
• Enclosure rating: IP67( Outdoor-NEMA6)
